The modular units for transportation control are used to control the flow of the workpiece pallets on the transfer system. The transportation control involves stopping and separating workpiece pallets, inquiring the position of workpiece pallets, controlling all function processes, etc.
Required accessories Sensor M12 circular with rated switching distance S<sub>N</sub> = 4 mm at vertical installation,Sensor M12 circular with rated switching distance S<sub>N</sub> = 8 mm at horizontal installation, WI 2/X or WI 2/D rocker
Scope of delivery Incl. fastening material,Including DA 2/100 damper, Including fastening material for installation on ST 2/... conveyor section or BS 2/... belt section.
Material information Housing: Aluminum, hard anodized,Stop cam: Steel, hardened, Housing: PA 6,Safety catch: Brass,Stop cam: PA 66, Housing: PA 6,Stop cam: PA 66
Material information Housing: aluminum, hard anodized,Stop cam: non-magnetic stainless steel; hardened, Housing: Aluminum, hard anodized,Stop cam: Steel, hardened, Housing: Plastic,Stop cam: Steel, hardened, Housing: Steel, coated,Stop cam: Steel, coated,Cross strut: Aluminum, natural; anodized, Housing: Steel,Stop cam: Steel,Cross strut: Aluminum
Operating temperature [T] max 0 ... +60 °C, 5 ... +60 °C
Recommended accessories Return stop VE 2/RS, VE 2/RS Return Stop, VE 2/RS Return Stop,Switch bracket for WT position inquiry,Position inquiry VE 2/D-80, VE 2/RS-H Return Stop
Scope of delivery Incl. all fastening material to mount on ST 2/... conveyor section, Incl. fastening material for assembly on the conveyor section ST 2/..., Incl. fastening material for assembly on the conveyor section ST 2/...,Pneumatic elements
Material information Housing: Aluminum, hard anodized,Stop: Steel, hardened, Housing: Aluminum, hard anodized,Stop: Steel, hardened,Section profile: Aluminum, natural; anodized
Material information Housing: Aluminum, hard anodized,Stop: Steel, hardened, Housing: Aluminum,Stop: Aluminum, Housing: aluminum; hard anodized,Latch: steel, Housing: PA 6,Safety catch: Brass,Stop cam: PA 66
Operating temperature [T] max -20 ... +80 °C, +60 °C, 60 °C
Pneumatic straight connection [Ø] 4 mm, 6 mm
Recommended accessories 2x sensor M8x1, Sensor M12x1, Sensor M12x1 with rated switching distance SN = 4 mm, overall length 45 mm,Clamping holder, Sensor M8x1
Height 8 mm, 15 mm, 33 mm, 35 mm, 53 mm, 86 mm, 88 mm
Length 25 mm, 40 mm, 55 mm, 65 mm, 82 mm, 90 mm, 98 mm
Required accessories M12x1 sensor with rated sensing range of S<sub>N </sub>≥ 4 mm, Sensor in flat special shape with rated sensing range S<sub>N</sub> ≥ 4 mm, e. g. Balluff BES 516-347-SA-2-03, Sensor M12, S<sub>N</sub> = 8 mm, L ≥ 44 mm can be installed flush or not flush, Sensor M12x1, S<sub>N</sub> = 8 mm, L ≥ 44 mm can be installed flush or not flush, Sensor M12x1, S<sub>N</sub> = 8 mm, L ≥ 60 mm can be installed flush or not flush, Sensor M12x1, SN = 8 mm, L ≥ 44 mm can be installed flush or not flush
Scope of delivery fastening material included, Incl. fastening material, Incl. fastening material for assembly on conveyor sections ST 2/...
